What is a DNS cache server? Explanation of core concepts and functions

in daily network access, we can quickly open the corresponding website by entering the domain name, which is inseparable from the support of the domain name system, and the DNS cache server is the key node to improve the resolution efficiency. Many users do not understand its operation logic and actual value. This article will disassemble the relevant knowledge of the DNS cache server in an all-round way from the core concept, operation mechanism, actual role to maintenance points, and help readers clearly understand the importance of this network infrastructure and master its core logic for optimizing network access.

What is the core concept of DNS cache server?

to understand the role of DNS cache server, we must first clarify its basic definition and core positioning.

1, the basic definition of DNS cache server

DNS cache server is a network server that specializes in storing the cache data of the correspondence between the domain name and the Internet Protocol Address. It is between the user end point and the authoritative DNS server. It does not need to store the complete domain name resolution database and only retains the recently queried resolution records. When the user initiates a domain name resolution request, it will preferentially retrieve data from the local cache to reduce the dependence on the upper server.

2, DNS cache server core positioning

it is essentially an "intermediate cache node" in the domain name resolution link, neither an authoritative server responsible for managing domain name resolution records nor an end point device for initiating requests, but provides users with faster resolution services by caching popular resolution records, while reducing the overall load of the entire domain name system.

What is the operating mechanism of DNS cache server?

understand the running process of the DNS cache server, you can see more clearly how it improves the resolution efficiency.

1, domain name resolution request reception and judgment

when the user end point initiates a domain name resolution request, it will be sent to the configured DNS cache server, the server will immediately check whether there is an Internet Protocol Address record corresponding to the domain name in the local cache, and confirm whether the record is within a valid period. If the conditions are met, the cache results will be directly returned to the user.

2, recursive query process when cache is missing

if there is no corresponding record in the local cache of the DNS cache server, or the record has expired, it will initiate a recursive query to the upper DNS server, starting from the root domain name server, and then obtain the correct resolution record through the top-level domain server and the authoritative domain name server. After storing the record in the local cache, it will be returned to the user end point.

3, update and elimination mechanism of cache records

DNS cache server will set a valid period for each cache record, the valid period is determined by the TTL value returned by the authoritative server, when the record is about to expire, the server will initiate a pre-query to update the cache in advance; at the same time, when the cache space is insufficient, It will eliminate the longest unaccessed records according to the LRU algorithm to ensure efficient use of cache resources.

What are the actual functions of the DNS cache server?

as an important component of network infrastructure, the actual role of DNS cache server runs through multiple links of network access.

1, greatly improve the speed of domain name resolution

this is the core role of the DNS cache server, after the user initiates the resolution request, there is no need to wait for the full-link process of recursive query, directly obtain the result from the local cache, and the resolution time can be shortened from hundreds of milliseconds to tens of milliseconds or even shorter.

2, reduce the overall load of the domain name system

a large number of repeated parsing requests are intercepted and processed by the DNS cache server, reducing the number of queries to the root domain name server and the authoritative domain name server, avoiding response delays or service interruptions due to request overload on the upper server, and ensuring the stable operation of the entire domain name system.

3, optimize local network access experience

for enterprise or local area network scenarios, after deploying the local DNS cache server, all users' resolution requests in the local area network can be processed locally to avoid the delay of cross-network queries, and at the same time, the local service domain name can be preferentially resolved through custom cache rules to further improve the access efficiency of the internal network.

What are the daily maintenance points of DNS cache server?

to make the DNS cache server continue to play a stable role, daily maintenance and optimization is essential.

1, regularly clean invalid cache records

although the DNS cache server has an automatic elimination mechanism, but some special scenarios, such as domain name change Internet Protocol Address, cache records may not be timely updated, this time the need to manually clean up the corresponding invalid cache, to avoid user access to the wrong server address, affecting the network access experience.

2, reasonable configuration of cache TTL parameters

administrator can adjust the TTL value of cache records according to network scenarios, for popular domain names with high stability, a longer TTL value can be set to improve cache utilization; for domain names that frequently change IP, a shorter TTL value is set to ensure the timeliness of parsing records, Balance parsing speed and recording accuracy.

3, monitor the server running status

to real-time monitoring DNS cache server request processing capacity, cache hit rate, response time and other key indicators, when the cache hit rate is too low or the response delay increases, timely troubleshooting reasons, such as whether there is insufficient cache space or upper-level server link failure, to ensure that the server is always in efficient operation.

sum up, DNS cache server is a key infrastructure to improve network access efficiency. From the core concept to the operation mechanism, to the actual role and maintenance points, each ring directly affects its service ability. It shortens the access time and reduces the load of the domain name system through cache resolution records. It plays an important role in both public networks and local area networks. Mastering its relevant knowledge can help us better optimize the network access experience and ensure the stable operation of network services.
